Description:

The C-20D Vertical 2-axis FPV Gimbal is compatible with a variety of digital FPV systems such as DJI O3, Walksnail Avatar, Walksnail Moonlight, and 19mm wide analog cameras. With a 2-axis mechanical stabilization structure and high-torque motors, the C-20D is able to provides an extreme stabilization effect against the vibration and highspeed airimpact.With the Headtracker, the C-20D provides an immersive high-quality firstperson control experience.

Feature:

- Compatible with a variety of digital FPV systems such as DJI O3, Walksnail Avatar, Walksnail Moonlight, and 19mm wide analog cameras or other devices.

- The main body is made of high performance polymer, which is extremely compressed in size and weight.

- With a 2-axis mechanical stabilization structure and high-torque motors, the C-20D is able to provides an extreme stabilization effect against the vibration and high-speed airimpact.

- Multiple stabilization modes are suitable for a variety of platforms such as RC cars, FPV fixed-wing planes and realistic RC planes.

- Supports Headtracker, UART(private protocol &MAVLink), S.BUS, CRSF and PWM control.

- Can be mounted whether downward or upward.

- 7.4~26.4 VDC wide voltag input.

Specification：

Brand: XF

Item Name: C-20D Vertical 2-Axis FPV Gimbal

General	Product Name:	C-20D
	Dimensions:	42 x50.9x55.7mm
	Weight:	36g
	Operating Voltag:	7.4~ 26.4VDC
	Power:	0.25W (AVGl) / 8W (Stall)
	Mounting:	Downward/ Upward
	Control Port:	Headtracker/ UART (private protocol &MAVLink)/ S.BUS / CRSF / PWM
Gimbal	Gimbal Type:	2-axis Mechanical Stabilization
	Angular Accuracy:	±0.005°
	Controllable Rang	Pitchh: -35°~+175°,Yaw: ±145°
	Max Rotation Speed:	±1500°/s
Camera Suitability	Maximu Weight:	20g
	Maximu Width:	19mm



Package included:

1x C-20D Vertical 2-Axis FPV Gimba

1x J1.0 Parameter Adjustment Module

1x Installation Tools
