Description
Note: DJI O4 Version Clink Here.
Feature:
- 2 Types of racks: Heison 5X & 5D, supporting 6S and 8S battery, DJI or analog VTX.
- Equipped with the advanced SEQURE H743 V2 FC & E70 G1 ESC, featuring STM32H743 MCU, ICM-42688P Gyro, and high-performance 32-bit 70A 4IN1 ESC, this specifications ensures an unparalleled flying experience.
- It pioneers personality-infused image projection for FPV drones, making it navigable in the dark night. Support DIY patterns to meet different scene requirements.
- Innovative Active Cooling System.Special aviation-grade heat dissipation ice armor reduces the heat generated by the VTX.The front air intake and active vortex generator together form a negative pressure air duct for efficient cooling.
- Innovative Full Coverage Arms, Motor wiring ingeniously concealed, Effective protection of motor wire safety and a more aesthetically pleasing layout.
- Fully enclosed combat armor with distinct edges and corners, Electrifying LED strips pulsate dynamically, Reserved Type-C Port for parameters tuning.
- 10th Generation GPS Module. Forward-facing unobstructed GPS design, eliminating VTX interference. Faster satellites searching and locking up to 32 satellites for stable rescue.
- The nose is constructed with aviation-grade 7075 aluminum, ensuring enhanced protection for the body and lens. The TPU shock-absorbing design on both sides effectively minimizes image vibrations during flight.
- Heison 5X delivers an even more impeccable freestyle feel, with more precise and agile stick response, indulging in the thrill of Freestyle.Heison 5D supports DJI O3 ultra-wide-angle without exposing propellers, enjoying high-speed flights with stunning visuals.
Specifications:
Brand: SEQURE
Model: Heison
Item Name: 5 Inch Freestyle Cine FPV Racing Drone
Type: 5X & 5D (Optional)
Frame |
Heison 5X |
Heison 5D |
Wheelbase |
220mm |
225mm |
Arm plate |
8mm |
|
Top plate |
3mm |
|
Bottom plate |
3mm |
|
Operating Voltage |
4-8S（14V-35V） |
|
Motors |
1800KV（6S），1600KV（8S） |
|
Flight Controller |
SEQURE H743 V2 |
|
Firmware |
SEQUREH7V2 |
|
MCU |
STM32H743 |
|
Gyro |
ICM-42688P |
|
ESC |
32-Bit 70A 4IN1 ESC |
|
OSD Chip |
AT7456E |
|
Black Box |
16MB |
|
Props |
Gemfan 51466 V2 |
|
Buzzer |
YES |
|
Recommended Battery |
6S LiPo/LiHV 1200-1500mah (6S Version) 8S LiPo/LiHV 1050-1400mah (8S Version) |
|
