Features of the 40A 2-6S Lipo ESC:

1. The twisted-pair design of the throttle signal cable effectively reduces the crosstalk produced in signal transmission and makes flight more stable.

2. Compatible with various flight controllers and supports a signal frequency of up to 621Hz. (Note: all throttle signals over 500Hz are non-standard signals.)

3. Fixed-wing dedicated core controllers greatly improve throttle response.

4. Compatible with multi-rotor controllers.

5. Highly intelligent, use easy, timing setting only

6. Timing: High Timing / Medium Timing.

Features of the 40A 3-4S ESC:

1. The ESC has the first-class quality and high reliability.

2. Strong flow resistance.

3. It has multiple protection functions such as input voltage abnormality protection, battery low voltage protection, overheats protection, and throttle signal loss protection.

4. It has three start modes: normal start, soft start, and super soft start, compatible with fixed-wing aircraft and helicopters.

5. Accelerator stroke can be set, and compatible with various remote controllers. It has a smooth and delicate speed control feel and first-class speed control linearity.

6. The maximum speed can reach 210000 RPM (2-pole motor), 70000 RPM (6-pole motor), and 35000 RPM (12-pole motor).



Specification:

Brand: QX-motor

Model: 40A 2-6S ESC / 40A 3-4S ESC (optional)

Model	Con.Current	Peak Current    (10S)	BEC	Lipo	Programmable Item	Weight	Size
40A 2-6S ESC	40A	60A	No	2-6S	Timing(High/ Intermediate)	26g	68x25x8.7mm
40A 3-4S ESC	40A	60A	5V 5A	3-4S	Low / Medium / High ( 3.75°/15°/26.25°)	36g	68x25x8mm

40A 3-4S ESC Manual, Click Here

Package Included:

1 x 40A ESC
