Camera: DJI O4
Receiver: ELRS 2.4GHz
Price:
R 7,419.69 R 11,139.54
Stock:
In Stock. Shipping via Courier.



We offer a 7 day replacement guarantee on all items that arrive defective or damaged. View our full policy here.



All payment methods are fully secure via SSL. We have the following payment methods available: Credit & Cheque Card; Instant EFT; QR Code Apps; Debit Card; MobiCred; and SCode.



Description


Introduction:

The Happymodel Mobula7 O4 micro FPV whoop comes out now . It comes with the new DJI O4 air unit which would provide excellent and unbelievable FPV footage. And the new Happymodel RS1102 KV10000 motor and HQPROP 45mm propellers ,bring a powerful and smooth flying experience. This would be a good option for indoor and backyard FPV flying.



Features:

- Equipment with New DJI O4 air unit

- 2S battery support Powerful and Smooth freestyle flying

- UART ExpressLRS receiver support stable control link

- Lighter and small for indoor FPV



Specifications:

Brand: Happymodel

Model: Mobula7

Item Name: DJI O4 2S FPV Drone

Motor

Mode: RS1102 KV10000
Configu-ration:9N12P
Stator Diamter:11mm
Stator Length:2mm
Shaft Diameter:Φ1.5mm
Motor Dimension(Dia.*Len):Φ13.5mm*14mm
Weight(g):2.8g
No.of Cells(Lipo):1-2S

Propellers

Weight:0.25g
Material: Poly Carbonate
Pitch:0.9
Props Dia:45mm
Hub Thickness:5mm
Shaft:1.5mm

Flight controller

MCU: STM32F405RGT6 (168MHZ, 1Mbyte FLASH)
GYRO Sensor: BMI270  (SPI connection)
Mount hole size: 25.5mm*25.5mm
Power supply: 1-2S battery input (DC 2.9V-8.7V)
Built-in 12A(each) Blheli_S 4in1 ESC
Built-in Serial ExpressLRS 2.4G

Built-in BMP280 Barometer

Built-in 8MBp blackbox
Built-in voltage meter sensor , voltage meter scale 110

Built-in current meter sensor , current meter scale 470

Onboard 4in1 ESC

Power supply: 1-2S LiPo/LiPo HV
Current: 12A continuous peak 15A (3 seconds)
Support BLHeli_S Bluejay firmware
Factory firmware: Bluejay ESC V0.19

Firmware target: Z-H-30
Default protocol: DSHOT300
When use 1s battery and high KV 0702/0802 motors, should set startup power to 1100/1200

Onboard UART ExpressLRS 2.4GHz Receiver

Packet Rate option: 25Hz/50Hz/150Hz/250Hz/500Hz
RF Frequency: 2.4GHz
Antenna: enameled copper wire 31mm length
Telemetry output Power: <12dBm
Default firmware version: ExpressLRS V3.0.1
Firmware target: HappyModel EP 2400 RX
Could update firmware via ExpressLRS configurator

DJI O4 Air Unit

Weight:

Air Unit (camera module included): Approx. 8.2 g

Transmission Module: 30×30×6 mm (L×W×H)

Camera Module: 13.44×12.36×16.50 mm (L×W×H)

Camera Cable Length: 50mm

Coaxial Cable: 50 mm

3-in-1 Cable: 50 mm

Operating Frequency:

5.170-5.250 GHz

5.725-5.850 GHz

Operating frequency varies by region. Refer to local regulations.

Transmitter Power (EIRP):

5.1 GHz: <23 dBm (CE)

5.8 GHz:

<30 dBm (FCC)

<14 dBm (CE)

<30 dBm (SRRC)

Live View Quality: 1080p at 30/50/60/100fps



Recommend Battery(Not Include): GNB  2s  380/450/550mah


Package Includes:

Item Name

Qty

Happymodel M80 Frame

1

CrazyF4HD ELRS flight controller firmware target:BETAFLIGHTF4

1

RS1102 KV10000 brushless motor

4

HQPROP 45MMX2 bi-blade propellers(4cw+4ccw)

1

DJI O4 Air unit

1

Canopy

1

Screw driver

1
