Description
Specifications:
Brand: HAKRC
Item Name: H743 12S Flight Controller
CPU: STM32H743VIT6 (Main Control Frequency: 480Hz)
IMU: ICM42688 Dual Gyroscope
OSD: AT7456E
Input Voltage: 6-12S
Barometer: SPA06-003
External Storage: MicroSD Card
BEC: 5V/3.5A
BEC:12V/3A
LED: Support External Adjustable LED
Firmware Version: HAKRC H743
Receiver: Frsky / Futba / Flysky / TBS CRSF / DSMX: DSM2 Receiver
Serial Ports: 8
Product Size: 40*40mm
Product Weight: 11.3g
Feature:
1. The PCB is made of high-end 6-layer 1oZ thickened copper skin, which has strong anti-interference ability.
2. Adopt double gyroscope design to reduce the error of one gyroscope.
3. Adopt industrial-grade LDO, high temperature resistance.
4. Comes with DJI sky straight socket, easy to install, solder-free.
5. Reserve the 5V power supply of the external LED strip light, and the remote control channel can be customized to control the switch of the strip light.
6. Image transmission power supply.
7. Adopt high-quality Japanese Murata capacitors, strong filtering performance.
8. Ten motor control signal output.
9. It can support Betaflight, Ardupilot, INAV and PX4 firmware.
10. Support digital video transmission and analog video transmission, and can support dual cameras.
11. Insert an external MicroSD card.
12. Support airspeed tube, magnetometer, data transmission.
13.8 serial port.
14. Support dual servos.
15. Support CAN port.
16. Support dual galvanometer interface, default C1, C1, C2 can be switched freely through the remote control.
Package included:
1 x HAKRC 12S H743 Flight Controller
