Description:

The Vapor-D features a DC structure that evolves from the Wide X version.

It delivers exceptional flight performance with the TAKER H60_BLS 60A 4-in-1 ESC and GEP-F722-HD V2 flight controller. Its unique DC design ensures the camera does not capture the propellers in view, boosting both video quality and flight enjoyment. With sleek CNC aluminum alloy side panels, the Vapor-D offers a perfect blend of style and strength.

Available in both 5-inch and 6-inch models, it’s made fo every pilot and every flying need



Feature:

- The DC structure, paired with the TAKER H60_BLS 60A 4-in-1 ESC and GEP-F722-HD V2 FC, ensures stable flight and excellent shooting.

- Boost maneuverability and power for stunning aerial footage with GEPRC SPEEDX2 E-series motors.

- The sleek side panels, crafted from CNC aluminum alloy, provide stylish yet sturdy protection for the camera.

- The front lens guard provides reliable protection during flights.

- The DC structure enhances both shooting quality and flying fun.

- Choose between 5-inch and 6-inch models to fit your flying preferences.



Specifications:

Brand: GEPRC

Model: Vapor D5 Analog

Item Name: 5 Inch 6S Freestyle FPV Drone

GPS: Geprc GEP M10 GPS

Model:	Vapor D5 Analog			Vapor D6 Analog
Version	Vapor D5 DJI O3 Air Unit	Vapor D5 Wasp	Vapor D5 Analog	Vapor D6 DJI O3 Air Unit	Vapor D6 Wasp	Vapor D6 Analog
VTX	DJI O3 Air Unit	Link	MATEN 5.8G 1.6W VTX	DJI O3 Air Unit	Link	MATEN 5.8G 1.6W VTX
Camera	DJI O3 Camera	Wasp	Caddx H1	DJI O3 Camera	Wasp	Caddx H1
Antenna	5.8G&2.4G	Momoda2 5.8G Antenna LHCP SMA 90mm	Momoda2 5.8G Antenna LHCP SMA 90mm	5.8G&2.4G	Momoda2 5.8G Antenna LHCP SMA 90mm	Momoda2 5.8G Antenna RHCP SMA 90mm
Weight	435g±5g	428±5g	428±5g	467g±5g	459±5g	460g±5g
Motors	GEPRC SPEEDX2 2207E 1960 KV			GEPRC SPEEDX2 2407E 1750KV
Propellers	GEMFAN 5136			HQ 6X3.5X3
Frame	Vapor-D5 frame			Vapor-D6 frame
Wheelbase	238.43mm			274.60mm
Flight Time	13min (1550mah)			17min (1800mah)
Top Plate	2.0 mm
Middle Plate	2.0mm
Bottom Plate
