Summary：
The MATEN 5.8G 3W VTX PRO is a high-performance VTX newly developed by the GEPRC team. With five adjustable power options and a dual-core design, it delivers up to 3000mW of power, ensuring stable signal transmission and excellent penetration.
Built with a high-strength CNC aluminum metal shell, the MATEN 5.8G 3W VTX PRO offers superior heat dissipation and impact resistance. Its sleek design features a fan cooling function for optimal performance, while the built-in micrphone transmits real-time audio from the FPV drone.
Supporting the IRC Tramp protocol, it allows you to adjust parameters through OSD. It operates within a voltag extent of 7-36V and includes temperature protection to prevent overheating and damage. With 80 transmission channels and two mounting options, 20x20mm (M2) and 30.5×30.5mm (M2), it’s the perfect VTX for any build.



Feature：
- Dual-core design, up to 3000mW, suitable for long extent fligh
- The well-chosen high-strength aluminum metal CNC shell assist heat dissipation
- The built-in micr turbofan dissipates heat actively
- Wide voltag input supports 7V-36V voltag input
- One function adjustment buttons, three indicator lights, easy to operate.
- VTX control protocol IRC Tramp supports OSD parameter adjustment.
- Temperature control protection function prevent overheat
- VTX built in micrphone,real-time transmission of sounds.
- Supports 80 transmission channels
- Support 20x20mm(M2) and 30.5×30.5mm(M2) two different mounting hole sizes

Specifications：

Model:	GEPRC MATEN 5.8G 3W VTX PRO
Frequency：	5.8G
Channels:	80CH
Output power:	25mW/200mW/600mW/1600mW/3000mW/Pit mode
Input voltag:	DC7-36V（2-8S Battery）
Output Voltag:	5V@600mA
Protocol:	IRC Tramp
Antenna Connector:	MMCX
Cable Connector:	SH1.0 6pin
Video Format:	PAL/NTSC
Micrphone:	Built-in micrphone
Weight:	21.1g
Mounting Hole Size：	20x20mm(M2),30.5×30.5mm(M2)
Dimension:	36.3×36.3×15.1mm
